AP MEMORY愛普科技股份有限公司(TWSE:6531)成立於2011年，營運總部位于臺灣新竹，是一家無晶圓廠客制化記憶體設計和IP解決方案的半導體公司。公司研發實力強大，研發團隊擁有二十多年的行業技術經驗，能提供多樣化的PSRAM存儲產品?，F(xiàn)已發展成為PSRAM的龍頭廠商。主要研發部門位于日本，美國和大中華地區，銷售地點遍布全球。
存儲器PSRAM(pseudo SRAM)，稱之為偽靜態隨機存取器。它具有SRAM的接口協議：給出地址、讀寫指令，就可以實現數據的存??；相比DRAM的實現，它不需要復雜的memory controller來控制內存單元去定期刷新數據，但是它的內核架構卻是DRAM架構；傳統的SRAM是由6個晶體管構成一個存儲cell，而psram則是由1個晶體管+一個電容構成一個存儲cell，因此psram可以實現較大的存儲容量；
基于上述分析，新出現的存儲器psram相比傳統存儲器具有如下優點：
1. 更大的帶寬：串行psram通過八路串行接口對外互聯，最高在200MHz Double-Data-Rate速率下，可實現超3Gbps的帶寬傳輸；
2. 更高的容量：目前可實現存儲容量有：32M、64M、256M，這比市面上其他串行接口隨機
存儲器的容量要大很多；
3. 更低的成本：串行psram采用DRAM架構，可以有效壓縮芯片體積，故串行psram生產成本接近DRAM成本；
4. 更小的尺寸：串行psram的低引腳數封裝與傳統的RAM存儲相比，具有尺寸更小、成本更低等優勢；
5. 更廣的應用：psram采用的是自行刷新（Self-Refresh），不需要刷新電路即能保存它內部存儲的數據；而DRAM每隔一段時間，要刷新充電一次，否則內部的數據即會消失，因此psram相比傳統RAM會有更廣的應用；
PSRAM作為常用的一種外設存儲設備，所具有的優點使其廣泛被應用。
apmemory愛普PSRAM芯片選型
IoT RAM Series
系列 | Part Number
型號 | Density
容量 | Voltage
工作電壓 | I/O Config. | Data Rate(Mbps)
速率 | Temperature Range
溫寬 | Status
狀態 | Notes |
| SPI/QSPI | APS1604M-SQR | 16Mb | 1.8V | ×4 | 144 | Tj = -40°C to +85°C | MP | Bare die, SIP |
| SPI/QSPI | APS1604M-SQRX | 16Mb | 1.8V | ×4 | 144 | Tj = -40°C to +105°C | MP | Bare die, SIP |
| SPI/QSPI | APS1604M-SQR-ZR | 16Mb | 1.8V | ×4 | 144 | Tc=-40°C to +85°C | MP | USON-8 |
| SPI/QSPI | APS1604M-SQR-SN | 16Mb | 1.8V | ×4 | 144 | Tc=-40°C to +85°C | MP | SOP-8 |
| SPI/QSPI | APS1604M-SQRX-SN | 16Mb | 1.8V | ×4 | 144 | Tc=-40°C to +105°C | MP | SOP-8 |
| SPI/QSPI | APS1604M-SQR-RB | 16Mb | 1.8V | ×4 |
| Tc=-40°C to +85°C |
|
|
| SPI/QSPI | APS1604M-3SQR | 16Mb | 3.0V | ×4 | 133 | Tj = -40°C to +85°C | MP | Bare die, SIP |
| SPI/QSPI | APS1604M-3SQRX | 16Mb | 3.0V | ×4 | 133 | Tj = -40°C to +105°C | MP | Bare die, SIP |
| SPI/QSPI | APS1604M-3SQR-ZR | 16Mb | 3.0V | ×4 | 133 | Tc=-40°C to +85°C | MP | USON-8 |
| SPI/QSPI | APS1604M-3SQR-SN | 16Mb | 3.0V | ×4 | 133 | Tc=-40°C to +85°C | MP | SOP-8 |
| SPI/QSPI | APS1604M-3SQRX-SN | 16Mb | 3.0V | ×4 | 133 | Tc=-40°C to +105°C | MP | SOP-8 |
| SPI/QSPI | APS1604M-DQRA | 16Mb | 1.8V | ×4 | 333 | Tj=-40°C to +85°C | MP | Bare die, SIP |
| SPI/QSPI | APS1604M-DQXRA | 16Mb | 1.8V | ×4 | 333 | Tj=-40°C to +105°C | MP | Bare die, SIP |
| SPI/QSPI | APS1604M-DQRA-BA | 16Mb | 1.8V | ×4 | 333 | Tc=-40°C to +85°C | MP | BGA 24B(Only for validation) |
| SPI/QSPI | APS3204L-3SQNA-SN | 32Mb | 3.0V | ×4 | 133 | Tc = -40°C to +105°C | MP | SOP-8 |
| SPI/QSPI | APS6404L-SQN | 64Mb | 1.8V | ×4 | 144 | Tj = -40°C to +85°C | MP | Bare die, SIP |
| SPI/QSPI | APS6404L-SQNX | 64Mb | 1.8V | ×4 | 144 | Tj = -40°C to +105°C | MP | Bare die, SIP |
| SPI/QSPI | APS6404L-SQN-ZR | 64Mb | 1.8V | ×4 | 144 | Tc = -40°C to +85°C | MP | USON-8 |
| SPI/QSPI | APS6404L-SQN-SN | 64Mb | 1.8V | ×4 | 144 | Tc = -40°C to +85°C | MP | SOP-8 |
| SPI/QSPI | APS6404L-SQNX-SN | 64Mb | 1.8V | ×4 | 144 | Tc = -40°C to +105°C | MP | SOP-8 |
| SPI/QSPI | APS6404L-3SQN | 64Mb | 3.0V | ×4 | 133 | Tj = -40°C to +85°C | MP | Bare die, SIP |
| SPI/QSPI | APS6404L-3SQNX | 64Mb | 3.0V | ×4 | 133 | Tj = -40°C to +105°C | MP | Bare die, SIP |
| SPI/QSPI | APS6404L-3SQN-ZR | 64Mb | 3.0V | ×4 | 133 | Tc = -40°C to +85°C | MP | USON-8 |
| SPI/QSPI | APS1604M-3SQR-SN | 64Mb | 3.0V | ×4 | 133 | Tc = -40°C to +85°C | MP | SOP-8 |
| SPI/QSPI | APS6404L-3SQNX-SN | 64Mb | 3.0V | ×4 | 133 | Tc = -40°C to +105°C | MP | SOP-8 |
| SPI/QSPI | APS6404L-SQR | 64Mb | 1.8V | ×4 | 144 | Tj = -40°C to +85°C | MP | Bare die, SIP |
| SPI/QSPI | APS6404L-SQRX | 64Mb | 1.8V | ×4 | 144 | Tj = -40°C to +105°C | MP | Bare die, SIP |
| SPI/QSPI | APS6404L-SQR-ZR | 64Mb | 1.8V | ×4 | 144 | Tc=-40°C to +85°C | MP | USON-8 |
| SPI/QSPI | APS6404L-SQR-SN | 64Mb | 1.8V | ×4 | 144 | Tc=-40°C to +85°C | MP | SOP-8 |
| SPI/QSPI | APS6404L-SQRX-SN | 64Mb | 1.8V | ×4 | 144 | Tc=-40°C to +105°C | MP | SOP-8 |
| SPI/QSPI | APS6404L-3SQR | 64Mb | 3.0V | ×4 | 133 | Tj=-40°C to +85°C | MP | Bare die, SIP |
| SPI/QSPI | APS6404L-3SQRX | 64Mb | 3.0V | ×4 | 133 | Tj=-40°C to +105°C | MP | Bare die, SIP |
| SPI/QSPI | APS6404L-3SQR-ZR | 64Mb | 3.0V | ×4 | 133 | Tc = -40°C to +85°C | MP | USON-8 |
| SPI/QSPI | APS6404L-3SQR-SN | 64Mb | 3.0V | ×4 | 133 | Tc = -40°C to +85°C | MP | SOP-8 |
| SPI/QSPI | APS6404L-3SQRX-SN | 64Mb | 3.0V | ×4 | 133 | Tc = -40°C to +105°C | MP | SOP-8 |
| SPI/QSPI | APS6404L-3SQN-SN | 64Mb | 3.0V | ×4 | 133 | Tc = -40°C to +85°C | MP |
|
| SPI/QSPI | APS6404L-SQH | 64Mb | 1.8V | ×4 | 144 | Tj = -40°C to +85°C | MP | Bare die, SIP |
| SPI/QSPI | APS6404L-SQHX | 64Mb | 1.8V | ×4 | 144 | Tj = -40°C to +105°C | MP | Bare die, SIP |
| SPI/QSPI | APS6404L-SQH-ZR | 64Mb | 1.8V | ×4 | 144 | Tc = -40°C to +85°C | MP | USON-8 |
| SPI/QSPI | APS6404L-SQH-SN | 64Mb | 1.8V | ×4 | 144 | Tc = -40°C to +85°C | MP | SOP-8 |
| SPI/QSPI | APS6404L-SQHX-SN | 64Mb | 1.8V | ×4 | 144 | Tc = -40°C to +105°C | MP | SOP-8 |
| SPI/QSPI | APS6404L-SQRHX-SN | 64Mb | 1.8V | ×4 | 144 | Tc = -40°C to +105°C | MP | SOP-8 |
| SPI/QSPI | APS6404L-SQRH-ZR | 64Mb | 1.8V | ×4 | 144 | Tc = -40°C to +85°C | MP | USON-8 |
| SPI/QSPI | APS6404L-SQRH-SN | 64Mb | 1.8V | ×4 | 144 | Tc = -40°C to +85°C | MP | SOP-8 |
| SPI/QSPI | APS12804O-SQRH | 128Mb | 1.8V | ×4 | 144 | Tj=-40°C to +85°C | MP | Bare die, SIP |
| SPI/QSPI | APS12804O-SQRHX | 128Mb | 1.8V | ×4 | 144 | Tj=-40°C to +105°C | MP | Bare die, SIP |
| SPI/QSPI | APS12804O-SQRH-SN | 128Mb | 1.8V | ×4 | 144 | Tc=-40°C to +85°C | MP | SOP8(Only for validation) |
| SPI/QSPI | APS12804O-SQRH-WA | 128Mb | 1.8V | ×4 | 144 | Tc=-40°C to +85°C | MP |
|
| SPI/QSPI | APS12804O-DQ | 128Mb | 1.8V | ×4 | 333 | Tj=-40°C to +85°C | MP | Bare die, SIP |
| SPI/QSPI | APS12804O-DQX | 128Mb | 1.8V | ×4 | 333 | Tj=-40°C to +105°C | MP | Bare die, SIP |
| SPI/QSPI | APS12804O-DQX-BA | 128Mb | 1.8V | ×4 | 333 | Tc=-40°C to +105°C | MP | BGA 24B(only for validation purpose) |
| OPI/HPI | APS6408L-OBM | 64Mb | 1.8V | ×8 | 400 | Tj= -40°C to +85°C | MP | Bare die, SIP |
| OPI/HPI | APS6408L-OBMX | 64Mb | 1.8V | ×8 | 400 | Tj= -40°C to +105°C | MP | Bare die, SIP |
| OPI/HPI | APS6408L-OBM-BA | 64Mb | 1.8V | ×8 | 400 | Tc= -40°C to +85°C | MP | BGA 24B |
| OPI/HPI | APS6408L-OBMX-BA | 64Mb | 1.8V | ×8 | 400 | Tc= -40°C to +105°C | MP | BGA 24 |
| OPI/HPI | APS6408L-OBM-WH | 64Mb | 1.8V | ×8 |
| Tc= -40°C to +85°C | MP |
|
| OPI/HPI | APS6408L-OB9 | 64Mb | 1.8V | ×8 | 400 | Tj= -40°C to +85°C | MP | Bare die, SIP |
| OPI/HPI | APS6408L-OBX9 | 64Mb | 1.8V | ×8 | 400 | Tj= -40°C to +105°C | MP | Bare die, SIP |
| OPI/HPI | APS6408L-OBX-BA | 64Mb | 1.8V | ×8 | 400 | Tc= -40°C to +105°C | MP | BGA 24B(only for validation purpose) |
| OPI/HPI | APS6408L-3OBM | 64Mb | 3.3V | ×8 | 266 | Tj= -40°C to +85°C | MP | Bare die, SIP |
| OPI/HPI | APS6408L-3OBMX | 64Mb | 3.3V | ×8 | 266 | Tj= -40°C to +105°C | MP | Bare die, SIP |
| OPI/HPI | APS6408L-3OBM-BA | 64Mb | 3.3V | ×8 | 266 | Tc= -40°C to +85°C | MP | BGA 24B |
| OPI/HPI | APS6408L-3OBMX-BA | 64Mb | 3.3V | ×8 | 266 | Tc= -40°C to +105°C | MP | BGA 24B |
| OPI/HPI | APS6408L-OCH-BA | 64Mb | 1.8V | ×8 | 400 | Tc=-40°C to +85°C | MP | BGA 24B |
| OPI/HPI | APS6408L-OCHX-BA | 64Mb | 1.8V | ×8 | 400 | Tc=-40°C to +105°C | MP | BGA 24B |
| OPI/HPI | APS6408L-3OC-BA | 64Mb | 3.3V | ×8 | 266 | Tc=-40°C to +85°C | MP | BGA 24 |
| OPI/HPI | APS6408L-3OCX-BA | 64Mb | 3.3V | ×8 | 266 | Tc=-40°C to +105°C | MP | 24b Package |
| OPI/HPI | APS12808L-OBM-BA | 128Mb | 1.8V | ×8 | 400 | Tc= -40°C to +85°C | MP | BGA 24B |
| OPI/HPI | APS12808L-OBMX-BA | 128Mb | 1.8V | ×8 | 400 | Tc= -40°C to +105°C | MP | BGA 24B |
| OPI/HPI | APS12808L-3OBM-BA | 128Mb | 3.3V | ×8 | 266 | Tc= -40°C to +85°C | MP | BGA 24B |
| OPI/HPI | APS12808L-3OBMX-BA | 128Mb | 3.3V | ×8 | 266 | Tc= -40°C to +105°C | MP | BGA 24B |
| OPI/HPI | APS128XXO-OB9 | 128Mb | 1.8V | ×8/×16 | 500 | Tj=-40°C to +85°C | MP | Bare die, SIP |
| OPI/HPI | APS128XXO-OBX9 | 128Mb | 1.8V | ×8/×16 | 500 | Tj=-40°C to +105°C | MP | Bare die, SIP |
| OPI/HPI | APS128XXO-OBRX-BG | 128Mb | 1.8V | ×8/×16 | 500 | Tc=-40°C to +105°C | MP | BGA 24B(only for validation purpose) |
| OPI/HPI | APS128XXN-OBRA-WA | 128Mb | 1.8V | ×8/×16 |
| Tc = -40°C to +85°C |
|
|
| OPI/HPI | APS25608N-OBR-BD | 256Mb | 1.8V | ×8 | 400 | Tc=-40°C to +85°C | MP | BGA 24B |
| OPI/HPI | APS25608N-OBRX-BD | 256Mb | 1.8V | ×8 | 400 | Tc=-40°C to +105°C | MP | BGA 24B |
| OPI/HPI | APS256XXN-OB9 | 256Mb | 1.8V | ×8/×16 | 500 | Tj=-40°C to +85°C | MP | Bare die, SIP |
| OPI/HPI | APS256XXN-OBx9 | 256Mb | 1.8V | ×8/×16 | 500 | Tj=-40°C to +105°C | MP | Bare die, SIP |
| OPI/HPI | APS256XXN-OB9-BG | 256Mb | 1.8V | ×8/×16 | 500 | Tc=-40°C to +85°C | MP | BGA 24B |
| OPI/HPI | APS256XXN-OBX9-BG | 256Mb | 1.8V | ×8/×16 | 500 | Tc=-40°C to +105°C | MP | BGA 24B |
| OPI/HPI | APS25608N-OCH-BD | 256Mb | 1.8V | ×8 | 400 | Tc = -40°C to +85°C | MP | BGA 24B |
| OPI/HPI | APS25608N-OCHX-BD | 256Mb | 1.8V | ×8 | 400 | Tc = -40°C to +105°C | MP | BGA 24B |
| OPI/HPI | APS51208N-OBR-BD | 512Mb | 1.8V | ×8 | 400 | Tc=-40°C to +85°C | MP | BGA 24B |
| OPI/HPI | APS51208N-OBRX-BD | 512Mb | 1.8V | ×8 | 400 | Tc=-40°C to +105°C | MP | BGA 24B |
| OPI/HPI | APS51208N-OCH-BD | 512Mb | 1.8V | ×8 | 400 | Tc = -40°C to +85°C | MP | BGA 24B |
| OPI/HPI | APS51208N-OCHX-BD | 512Mb | 1.8V | ×8 | 400 | Tc = -40°C to +105°C | MP | BGA 24B |
| OPI/HPI | APS512XXN-OBR-BG | 512Mb | 1.8V | ×8/×16 | 500 | Tc = -40°C to +85°C | MP | BGA 24B |
| OPI/HPI | APS512XXN-OB9-WB | 512Mb | 1.8V | ×8/×16 | 500 | Tc = -40°C to +85°C | MP | WLCSP-24 |
| OPI/HPI | APS512XXN-OB9-BG | 512Mb | 1.8V | ×8/×16 | 500 | Tc = -40°C to +85°C | MP | BGA-24 |
| OPI_LV/HPI_LV | APS128XXD-AOB7N | 128Mb | 1.2V/1.8V | ×8/×16 | 532 | Tc = -40°C to +85°C
Tc=-40°C to +105°C | UD | KGD/WLCSP |
| OPI_LV/HPI_LV | APS256XXN-AOB4N | 256Mb | 1.2V/1.8V | ×8/×16 | 332 | Tc = -40°C to +85°C | CS | WLCSP |
| OPI_LV/HPI_LV | APS256XXB-AOB5A | 256Mb | 1.2V/1.8V | ×8/×16 | 400 | Tc = -40°C to +85°C
Tc=-40°C to +105°C | CS | KGD |
| OPI_LV/HPI_LV | APS512XXN-AOB4N | 512Mb | 1.2V/1.8V | ×8/×16 | 332 | Tc = -40°C to +85°C
Tc=-40°C to +105°C | CS | WLCSP |
| UHS | AP26408A-0K2 | 64Mb | 1.8V | ×8 | 1334 | Tc = -40°C to +85°C
Tc=-40°C to +105°C | MP | KGD |
| UHS | AP36408B-OK2 | 64Mb | 1.2V/1.8V | ×8 | 2133 | Tc = -40°C to +85°C
Tc=-40°C to +105°C | MP | KGD |
| UHS | AP325608A-OK | 256Mb | 1.2V/1.8V | ×8 | 2133 | Tc = -40°C to +85°C
Tc=-40°C to +105°C | MP | KGD |
| UHS | AP325616A-OK | 256Mb | 1.2V/1.8V | ×16 | 2133 | Tc = -40°C to +85°C
Tc=-40°C to +105°C | MP | KGD |
| UHS | AP351208C-OK | 512Mb | 1.2V/1.8V | ×8 | 2133 | Tc = -40°C to +85°C
Tc=-40°C to +105°C | MP | KGD |
| UHS | AP351216C-OK | 512Mb | 1.2V/1.8V | ×16 | 2133 | Tc = -40°C to +85°C
Tc=-40°C to +105°C | MP | KGD |
